| Brand Name : | VAVTT or OEM |
| Model Number : | 32A LR32 29A L822 |
| Certification : | CE ROHS MSDS REACH SGS |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 1000000Pcs Per Month |
| Delivery Time : | 15-20 work days |
9V 32A LR32 29A L822 28mAh Alkaline Battery Doorbell Car Alarm Car Remote Control Flashlights
Description:
The 9V 32A Alkaline Battery is worked in Dog Training Shock Collar, car alarm remote and other .And it has a low power consumption and is energy-saving. With no pollution, no infrared and no thermal radiation, It is also easy to install, affordable, and a high quality Battery.
Equivalent to: 32A/ 29A/ L822/ A32 / G32A / 32A / GP32A / A32 / L822 / L822 / EL822 / EL-822/ GP29A / 29A / A29/GP25A / 25A / 25A
Applications:
Electric shock stop barking, Cosmetic pen, AE1 camera,Remote control,Electronic scales,Electronic toys,Computers,Game consoles,Anti-bark collar, Laser pointer, Alarm clock, Car Alarm Remote and other equipment.
Specifications:
| Nominal Voltage | 9V | ||
| Nominal Capacity (Continuous Discharging Under 20kΩ load to 6V End-Voltage at 20℃) | 28mAh | ||
| Operating temperature range | -20℃~60℃ | ||
 | A(ref.) | 0.55～0.75 | |
| B | 21.75-22.00 | ||
| C | 7.80~7.85 | ||
| D(ref.) | -0.05 | ||
| Mass | Approx 3.45g | ||
| Open-circuit Voltage | 9.3V | ||
| Appearance and poles | Appearance should be smooth, clear mark, no deformation, rust, and leakage | ||
| Minimum Average Discharge Time(20kΩ) | Initial test (New battery) | 55h | |
| After 12 months | 48h | ||
| Leakage Characteristics (Over discharge) | No Leakage | ||
Competitive Advantage:
1) Environmental friendly,Light weight
2) High density of energy
3) Low self-discharge
4) Low internal resistance
5) No memory effect
6) Free of mercury
7) Safety assurance : No fire, No explosion, No leakage
Discharge Curve:(Condition: Continuous Discharging Under 1kΩ load to 6V End-Voltage at 20℃)
Discharge Curve:(Condition: Continuous Discharging Under 20kΩ load to 6V End-Voltage at 20℃)
Tag:High Voltage battery,Alkaline battery
|
|
